Signal Point West Bedroom Radio Inventory


Above Closets

Box 1

CD ROM drives, including 2 Sony CD-R/RW, new Jan 05
U.S. Robotics 56K PCI FAXModem, new in box
Linksys Fast Ethernet 10/100 NIC card, new in box
PC case fan - snap-in
Keyspan COM port adapter

Box 1a

Daiwa CN-720 SWR Meter
Wireless G PCI Adapter (New)
nVidia G-Force 6200 PCI video cards (3 each) Win XP
New Netgear Prosafe Router Box + CD
K6AM/W8TK 2OSR Audio Boxes + Cables
MFJ-852 Power Line Noise Meter
Spare CPU for PC3

Box 2

Bag containing RTTY SignalLink and related cables for K3 and MMTY
Bag of FT-1000 FSK RTTY interface cables
Rigblaster, cables, software in box

West Mountain Radio Power Analyzer
West Mountain Radio DC regulator on heat sink
Rigblaster Pro and all cables
Rigblaster Pro manual
BuxComm GLX Mark V RTTY interface kit (2)
Anderson Powerpole connectors and cables
Titan II GU-91B chimney fabrication kit
ASUS router accessories (gain antennas)
2 RigRunner 4005 (one labeled K8ND)
1 roll new #18 red/black zip wire
Various red/black PowerPole cables
HamSource EZ Meter 2 digital current meter

Box 2a

DX Engineering Four Square Components
F connector crimping tool and F coax connectors

Box 3

W8WTS Unum transformers (2)
Spare 160 Unum
Bencher YA-1 low pass filters (2)
Alpha Delta four pole coax switch
Alpha Delta two pole coax switch

MFJ 2 pole RX antenna coax switch
B&W 2 pole can coax switch (2)
Kenwood RX antenna adapter boxes (2)
SB-200 linear relay isolation box
B&W 590 five pole axial rotary switch (bad)
Dow-Key 6 posn coax sw (2 each)
B&W six position coax rotary switch, axial on back
7/8 inch hardline connector directions + application aid
B&W six position linear switches (Dayton 2009) (2)
Bag of knobs for coax switches (Dayton 2009)
Daiwa 1 x 2 coax switch (2 each) (One may be bad.)

Box 3a

DX Engineering Four Square Components

Box 4

RFI kit: ferrites, AC line filters, Corcom filters
New Corcom 10FC12 power line filter

Box 4a

Full size muffin fans (2)
Miniature muffin fans (4) (new) (for triplexer that did not fit)
Miniature muffin fans (2) (used)
Biscuit blower fan
Muffin fan stilt kit
All pulleys
Goose guy grips

Box 5 EBR

Quick disconnect connectors for rotors (many)
Top Ten Devices Band Decoder control box (new)
Parts for Band Decoder control box
Top Ten Devices six pole coax box (used)
Box of rotor parts
Small Daiwa cross needle wattmeter

Box 5a EBR

CPU heat sink, from Shovic PC
Digital VTVM (new in box)
RigBlaster Cable Kit + CD
2 RigRunners (6 port) + DC Cables
Grommets, Assorted
RigRunner Power Crimp Tool
Titan III loading capacitor (new)
Netgear FA120 USB to Ethernet fast adapter, new in box
DSL RFI-proofing components (W8WTS, January 2009)
Titan III HV Board
Jones female connectors
Spare rotary switches for Stn 3 filter
Titan 425 screws
Titan III cabinet screws

Box 6

Titan III QSK Board (New from factory Spring 2009)
Titan III QSK Board (Bad, unrepairable at factory - parts only)
Titan III Screen Grid Board

StackMatch Specialized Expert's Kit
, test cable, dummy loads, schematics
Good StackMatch tower box
Bad StackMatch tower board (spare parts source)
Good StackMatch control box (new)
StackMatch tower board good, except ports 2 and 3 together (OK for 20 or 15 meter system replacement)
Top Ten Devices six pole remote coax switch
W8WTS hardline splice kit, complete

Box 6a

3 Bencher paddles
1 N0YY Vibro-Keyer paddle
1 Curtis K5 Lil Bugger
Winkeyers - 5 (older version)
Bag of LPT1 adapters
October 2010 Winkeyer CD
Bag of all possible CW system cables
2 Logikeyer battery holders
W8TK legacy Logikeyers - 3

Box 7

Antenna parts, insulators, large hardware
One new Cush-Craft A3-S or A-3WS center insulator

W8TK AM radio signal sniffer
Spare (new) Bencher Skyhawk balun
Coax balun for 10, 15, 20 tribander (made March 2014 by W0CG); has eyelet lugs and PL-259
N4RV PVC tubing to possibly replace Force 12 element insulators

Box 8

RCS-4 coax switch (inside and outside parts) (1 each)
RCS-4 inside control box (formerly Ridge control)

RCS-8V coax switch (inside and outside parts) (1 each)
Foot switches + N8LGP foot switches

Box 9 EBR

4CX800 (2) (new) (Titan III), added July 2006
Package of 8 HV electrolytics for AL-1200, new Jan 2016
AL-1200 tube socket: Eimac SK-410
Plastic bag with AL-1200 RF choke, Titan III HV resistors, Titan 425 HV ceramic caps
AL-1200 chimney (now in EBR chest of drawers)
3CX800A7, very soft, removed from W0CG lightning-damaged Titan 425
3CX1200A7 new added 6 Dec 2012
3CX1200A7 (30) added December 2016
8874 (3) removed from WI9WI amp, soft

Plastic bag with AL-1200 electronic bias board and docs, Feb 2011
Two new (Jan 2011) AL-1200 HV power supply boards including electrolytics EBR (removed 29 Nov 2015)
One old AL-1200 HV power supply board removed from AL-1200 (2) Nov 2011, cleaned by K8LEE; "may" be good

Plastic bag of Alpha parts: yellow lamp caps, 12W 10 ohm wirewound, alignment tool
Plastic box containing:

T/R relays for Titan III (3)
K1 reed relay and two K1 T/R relays new December 2012
Alpha 78 assorted DC control relays
AL-1200 parasitic suppressor
Misc LK-800 hardware
Bag LK-800 misc parts
Alpha power resistors, composition
AL-1200 HV supply resistors, current and older model design
AL-1200 new T/R board
Removed AL-1200 T/R board, possibly good

Below is T/R boards and caps for AL-1200 (1) bought by K8ND March 2016. These will go in Box 9.



Box 10

3CX800A7 (22, 23) Removed from LK-800 Jan 2006
3CPX800A7 fused to phenolic chimney base (28) Removed from LK-800 February 2013
8874 (3) (used)
8874 (new) (3)

3CPX800A7 (2 each) (new)
3CX1200A7 removed from AL-1200 4 Mar 2004
3CX1200A7 (New October 2010 from VY1EI, tested good Dec 2010)

Box 11

IBS-1 (2 each) with connection wiring
Top Ten Devices band decoder switch box from Stn 1
Elecraft XG2 RX test signal generator
IC-765 accessory bags
Omni VI accessroy box
Electrolytics removed from amplifiers

Box 12

Plaques

Box 13

Plaques
Acoustical Muffin Fans (5) (12 VDC)

Box 14

Three 3CX1200A7 35, 36, 38 (K8ND Nov 2015)
Four good Logikeyers WBR



Loose Items

N7BG 204-BAS Yagi, complete

KN7Y 155-BAS 15 meter yagi, complete

N8LGP obstruction light bracket

Line voltage meter - from Stn 1 Feb 2015

GAC-45 concrete guy anchors (2) (W0CG)

Cardboard box with parts for KN7Y 15 meter yagi

Five CCC rotors

Power Designs Model 5015T variable voltage bench power supply (W8AV)

Tower obstruction light (W8AV)

Three Hy-Gain rotor control boxes (N8NR)

W0CG Universal Mast Tool (October 2014)

Rohn TB-3 thrust bearing, new September 2014

Cardboard box with Autek WM-1 (5)

MFJ-870 Peak Reading Wattmeter

DX Engineering Feedline Current Choke (K8ND)

PJ9JT 220 V 2.5 KVA Variac

MFJ-986 Differential T Antenna Tuner

Palstar DL2K Dummy Load (W8TK)

MFJ-434 Voice Keyer (WB9Z)

MFJ-434B Voice Keyer (N0YY)

MFJ-4225V 2 amp switching power supply + Powerpole cable

PK-232 TNC (NW0L)

Astron RS-12

Astron RS-20

Astron RS-35M (2)

Radio Shack 20 amp switching DC supply

Cardboard box of unshielded Ethernet and serial network cables

Cardboard box of PJ9JT relays

New UTS telephone

New W0NB telephone

GE answering machine, removed from sunroom

GE clock radio, removed from East bedroom

Plastic wall-mounted spotlight fixture

Two good driven element traps for CL-33

2 Hy-Gain boom to mast mounting clamps and hardware

Bag of element and boom caps behind Box 10

Ameritron RCS-4 outside box, removed from service

RCS-8V relay box and five position controller, formerly "80 System"


Radio Closet (Right Closet)

Left Shelves (1)

Startek counter
Timewave DSP unit
Titan II parts/boards bin, including Titan II/III HV board
Amplifier parts box (AL-1200, LK-800) including new 1620 panel lamps
Box of K6AM mod kits


Batteries bins (2)
Fuses in coffee cans
Amp parts bin
XCVR parts bin

Hung:

Jones plugs

Left Shelves (2)

Red Box
Red Box 2 bin
White cardboard box with K3 cables from KB7Q

Yellow DVM
Triplett VOM
Simpson 260 VOM (W9JUV)

LK-800 parts bin
MFJ-259
Rig Expert AA-54

Coax connectors bins (2)
Amp parts box
Everything K3 box
FT-2000 Accessories and W9NJY Switch Parts box


Right Shelves (1)

Soldering materials in three-drawer cabinet
Miscellaneous tape bins (2)
Cheap tape bins (2)
Scotch 33 bins

Hung:

Rivet gun and rivets
Clip leads
DC cables assortment
Caulk gun
Rubber feet


Right Shelves (2)

Wrenches
Hand tools
Wall anchors and bits
Levels
Stepdown transformers
AL-1200 filament transformer
Titan II screen transformer
Titan III screen transformer (removed, possibly bad)

Three drawer cabinet with drill bits, Allen wrenches
Screen tool
Hacksaw blades
Heat gun

Rear Hung:

AC bricks
Coax jumpers
DC and signal cables
Computer cables
AC power cables

Hung on Bar:

Headphones
W0CG climbing belt
K8ND climbing belt/harness


Floor

AC box
Ext cords and power tools box
Grey antenna hardware metal toolbox
Gloves box
Tiewraps box
Nails box
Software box
Plumbing box (Sterlite blue), includes spare outdoor shower cartridge
Chemicals boxes
Duct Seal bricks
Household repairs box
Kent State
Internet switch, 3Com
DeWalt DC925KA battery operated drill kit (Sept 08)
9" x 12" x 1/8" aluminum plate

3" x 13.5" x 1/8" aluminum plate

Hung:

Pulleys
Crowbar
Hand Sledge
100 foot rule
Tile tools including grout float



Left Closet

Hanging

Coax jumpers
2 W2VJN filter stubs

Floor, General

Box with climbing equipment

Floor, Back Left Corner

200 ft # 4 bare copper
~180 ft 8 cond rotor cable (black) 6 # 18   2 # 16
120 ft #8 stranded insulated green
25 ft #8 stranded insulated black
1000 ft #14 green for DXE 4sq
350 ft #12 insulated stranded blue
380 ft 3x + shield grey Belden
Approx 800 ft #14 high quality antenna wire
Large coil #14 yellow solid wire
Two lengths RG-8/X approx 50ft and 110 ft connected together, coiled
500 ft reel #12 solid insulated red
350 ft reel #12 solid insulated black
400 ft reel #12 solid insulated green
500 ft reel #12 solid insulated black
500 ft reel #12 solid insulated blue (Still in Idaho Oct 2014)

Floor, Front Left Corner

DXE RG6 on coil
Coax for flags: 500 ft x 2
Coil of brown DC wire for DXE four square

Floor, Back Right Corner

RG-11
75 m dipole
Very long Belden 8214
Times 50 ohm LMR
RG-6
US/JA 15 yagi premade pigtail x 2
RG-8X (100 ft ?) with label that says "bad shield"
Bucket of Ethernet cables, some shielded
Box of white CAT5 cable, 5 cond, probably 200 ft
Leftover 9913 from US/JA tower
30 ft coil of white 7 cond security system cable
Coil 130 ft 6 cond rotor cable leftover from Stackmatch on US tower
Coil 115 ft 6 cond rotor cable leftover from Stackmatch on US tower
Large orange coil of two cond with shield
25 ft white insulated #9 stranded copper wire
200 ft coil of grey 3 cond + shield Belden cable
Trash bag containing CL-33 traps500 ft reel #12 solid insulated white
45 ft 3-conductor #14 solid European wire (grey)
RG-58/U tuneup pigtail (with balun) for 80 vee beam (K6AM) Instructions in "Antennas" folder in WBR.

Floor, Front Right Corner

25 ft Cu strap
500 ft ? # 14 black solid on two separate wood reels
World ham map
Bin of Ethernet cables

Right Shelves

Towels and linens
MFJ-434B Voice Keyer

Left Top Shelf

Keyspan adapters, ribbon cables, gender changers box (added Oct 2011)
Bag of jewel cases
Box and bag of mice
Two leftover IBS-1 intelligent band switches
Bag of mouse pads

Left Bottom Shelf

Internet switches (2)
Coil 500 ft 3/16" black dacron antenna rope - high quality
Short coil of 1/16" black antenna rope
About 700 ft coil of 1/8" black antenna rope
Nearly full coil of black antenna rope, lighter in weight than the above
#22 stranded white wire
Plastic box of antenna rope segments
Pkg of DVD-R discs
Comtrend DSL MODEM spare power supply, CD, cables
White bag with parts for N0YY power table
Tan rebuilt (good) StackMatch tower box

Under West Bed

Flag RX antennas

Under East Bed

5 foot utility table
3 black plastic cable reels (
unassembled)
















Left Closet

Left Shelves

Ballcaps (hung)
Former radio closet items


Right Shelves

Towels

Floor

18 60 x 60 tiles, shack room
33 50 x 50 tiles terrace mock marble
28 sunroom patio tiles
10 roof tiles

125 ft RG-6 (Nov 2014)

Bin of Ethernet cables
1000 ft dacron line (black)
Dropcloths
100 ft Carol 7 conductor #18 (white)
1 W2VJN stub 40 nulls 15
Bottom 15 yagi feedline and balun
Spare coax pigtail and balun for future
100ft + RG-213 (new)
250 ft heavy duty rotor cable
300 ft #12 stranded blue antenna wire
Various coax jumpers
Former 10 meter yagi feedline (painted)
500 ft 5/15 antenna rope (black)
RG-11 - various short lengths
Coil grey 8 cond DC cable, maybe 25 ft.
Coil grey 7 cond DC cable, maybe 25 ft.




Box Labels

Box 1

CD ROM Drives
MODEMS
NIC Cards





Box 2

Rigblaster and West Mountain Radio
RTTY Kits and Cables
Anderson Powerpole Connectors
Titan II GU-91B Chimney





Box 3

Unum Transformers
Low Pass Filters
Coax Switches
Kenwood RX Antenna Boxes




Box 4

Muffin Fans
Fan Stilt Kit
RFI Kit / Ferrites

HEAVY







Box 5

Quick Disconnects
Rotor Parts
Top Ten Band Decoders
Top Ten Six Pole Coax Switches
Wattmeters




Box 6

StackMatch Specialized Expert's Kit
StackMatches
Top Ten Six Pole Coax Switches







Box 7

Antenna Parts, Insulators, Large Hardware
W8TK AM Signal Sniffer

HEAVY





Box 8

RCS-4 Coax Switch
RCS-8V Coax Switch
Foot Switches







Box 9

Transmitting Tubes







Box 10

Transmitting Tubes
